| 產品型號 |
配套 圓環(huán) 鏈直徑 |
主要尺寸 mm |
約重 kg |
安全 工作 載荷 t |
備注 | ||||
|---|---|---|---|---|---|---|---|---|---|
| A | B | D | E | R | |||||
| HB06043/1 | 6 | 10 | 24 | 16 | 43 | 133 | 0.38 | 1 | H-5000B |
| HB08026/1.5 | 8 | 9 | 16 | 15 | 26 | 78 | 0.23 | 1.5 | H-1500T |
| HB08026/2 | 8 | 11 | 15 | 21 | 17 | 78 | 0.55 | 2 | H-2000S |
| HB10035/3 | 10 | 12 | 18 | 20 | 35 | 94 | 0.5 | 3 | H-6800T |
| HB10040/2.5 | 10 | 11 | 20 | 21 | 40 | 95 | 0.4 | 2.5 | H-5000T |
| HB10040/2.5×1 | 10 | 11 | 20 | 18 | 40 | 95 | 0.45 | 2.5 | H-5000TL |
| HB10049/3 | 10 | 20 | 31 | 27 | 49 | 132 | 1.1 | 3 | H-3000L |
| HB10050/2.9 | 10 | 12 | 21 | 20 | 50 | 97 | 0.5 | 2.9 | H6500T |
| HB10052/3.2 | 10 | 13 | 21 | 20 | 52 | 129 | 0.68 | 3.2 | H-7000T |
| HB12060/3.2 | 12 | 14 | 31 | 22 | 60 | 128 | 0.75 | 3.2 | H-3200L |
| HB12077/3.8 | 12 | 15 | 31 | 25 | 77 | 150 | 1.25 | 3.8 | H-3800L |
| HB13057/5 | 13 | 21 | 33 | 30 | 57 | 148 | 1.8 | 5 | H-5000L |
| HB14062/6 | 14 | 23 | 36 | 29 | 62 | 165 | 2.4 | 6 | H-6000L |
| HB16060/8 | 16 | 23 | 49 | 36 | 60 | 182 | 3.3 | 8 | H-8000L |
